91Connection
HBMQuantumX
6.4 MX440A universal amplifier
You can connect up to eight transducers to the universal amplifier MX440A. The transducers
are connected via 15-pin D-SUB-15HD device connectors. All measuring channels are
electrically isolated von one another and from the mains.
The transducer types that can be connected and the status display are identical to those of
the MX840A universal amplifier (see page 87).
System LED
Connection LED
Fig.6.6: MX440A front view
