HBM QuantumX MX840A - DC Power Sources 20 Ma − Voltage Fed

128 Connection
HBM QuantumX
6.11.15 DC power sources 20 mA − voltage fed
Supported by modules: MX840, MX840A, MX440A, MX410, MX1601
Pin assignment for the MX1601 module see chapter 6.9.1
(+)
(−)
Cable shield
Hsg. = housing
I
13
11
Geh.
12
9
4
1
5
6
10
11
15
1
8
Push in
6
7
2
8
4
5
3
6
1
123
1-wire EEPROM
(view from below)
2 Data
3 No function
1
MX1601
Adjustable sensor supply:
5 V … 24 V:
0 V:
Pin 12
Pin 11
Pin 6
Pin 7
Maximum current "30 mA
The sensor supply needs to be connected in series. However, this eliminates the electrical
isolation from the module supply. This applies for MX840A, MX840, MX410 and MX440A.
