65Connection
HBMQuantumX
5.2.9 Output of the inputs of several measurement
modules via CANbus
Isochronously parameterized signals can be output.
The parameterization is permanently stored in the modules (EEPROM).
*.dbc
4x
MX471
KAB269
KAB269
Fig.5.10: Output via CANbus
