HBM QuantumX MX840A - Inductive Half Bridges

116 Connection
HBM QuantumX
6.11.5 Inductive half bridges
Supported by modules: MX840, MX840A, MX440A, MX410
8
7
4
9
Hsg.
2
3
5
Cable color code:
wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
wh
bk
bu
gn
gy
ye
Measurement signal (+)
Excitation (+)
Sense lead (−)
Sense lead (+)
Excitation (−)
Cable shield
Hsg. = housing
6
1
123
1-wire EEPROM
(optional)
view from below
1
5
6
10
11
15
2 Data
3 No function
1
