164 Accessories
HBM QuantumX
9 Accessories
System accessories
Article Description Order No.
Module carrier QuantumX (standard) Module carrier for maximum 9 modules of the QuantumX
family;
General information:
− Wall or control cabinet installation (19”);
− Connection of external modules via FireWire possible;
− Power supply: 24 V DC;
− Power consumption: Max 5 A (150 W);
Note: Only modules with degree of protection IP20 can be
inserted.
1-BPX001
Housing connection element for QuantumX
modules
Mechanical connection elements for QuantumX modules
(IP20 / IP65); Set consisting of 2 housing clips, including
assembly material for fast connection of 2 modules.
1-CASECLIP
Module accessories
Voltage supply
IP20 IP65
AC−DC plug−in power supply unit; Input: 100-240 V
AC ("10%);
1.5 m cable with international plug set
Output: 24 V DC, Max. 1.25 A; 2 m cable with plug for
IP20 modules
Connector − Voltage supply QuantumX
(module in protection class IP65)
Order No.: 1-NTX001 Order No.: 1-CON−P1001
3 m cable for voltage supply of a QuantumX module;
Plug for IP20 modules on one side and exposed
wires at the other end.
Note when using multiple modules: The supply
voltage can be looped through FireWire connections
(max. 1.5 A)
Order No.: 1-KAB271-3
Mechanic
IP20 IP65
1−CASEFIT Fitting panel for mounting of QuantumX modules
using case clips (1−CASECLIP), lashing strap or
cable tie. Basic fastening by 4 screws
Order No.: 1-CASEFIT
1−CASEPROT Case protection functioning as stacking aid for MX
amplifiers, including material for fast mounting.
Order No.: 1-CASEPROT
