92 Connection
HBM QuantumX
6.5 MX410 highly dynamic universal amplifier
You can connect up to four transducers to the highly dynamic universal amplifier MX410. The
transducers are connected via 15-pin D-SUB-15HD device connectors. You will need BNC
adapters (accessories 1-IEPE-MX410) for the connection of IEPE transducers.
All measuring channels are electrically isolated von one another and from the mains. When
using the adjustable transducer excitation, electrical isolation from the supply voltage of the
amplifier is not required.
MX410 Connectable transducers
Transducer type Connector sockets see page
Full-bridge strain gauges 1 ... 40 112
Inductive transducers 1 ... 4 113
Inductive transducers 1 ... 4 116
Half-bridge strain gauges 1 ... 4 115
Quarter bridge via Adapter 1 ... 8 LEERER MERKER
Voltage 1 ... 4 125, 126
Current 1 ... 4 127
Current fed piezoelectric transducer
(IEPE, ICP
)
1 ... 8 122
Current fied resistiv transducer 1 ... 4 114
