48 BPX001 Backplane
HBM QuantumX
4.5.6 Synchronizing a system setup with multiple
backplanes
CX27 gateway modules enable several BPX backplanes to be synchronized.
CX27-to-CX27 connection using KAB272-2 or -5 via FireWire socket on the front.
Fig. 4.25: Synchronisieren mehrerer Modulträger
