HBM QuantumX MX840A - DC Voltage Sources 100 MV

125Connection
HBMQuantumX
6.11.12 DC voltage sources 100 mV
Supported by modules: MX840, MX840A, MX440A, MX1601
Pin assignment for the MX1601 module see chapter 6.9.1
10
4
Hsg.
5
9
(+)
(−)
Cable shield
U
Hsg.=Housing
6
1
123
1
5
6
10
11
15
2 Data
3 No function
1
1-wire EEPROM
(optional)
(view from below)
1
8
Push in
1
2
4
5
8
Maximum input voltage to housing and signal
ground :
MX840, MX840A, MX440A: "60 V
MX1601: "40 V
Adjustable sensor supply:
5 V … 24 V:
0 V:
Pin 12
Pin 11
Pin 6
Pin 7
MX1601
