HBM QuantumX MX840A - Frequency Measurement with Directional Signal (Single−Pole Mode)

136 Connection
HBM QuantumX
6.11.22 Frequency measurement with directional signal
(single−pole mode)
Supported by modules: MX840, MX840A, MX440A, MX460
10
8
Industrial
pulse
generator
f
2
(+)
f
1
(+)
6
4
5
7
9
5 V
3.5 V
1.5 V
Thresholds
Thresholds
f
1
Schematic diagram; single−pole mode
0 V
Hsg.
Cable shield
Hsg. = housing
6
1
123
1-wire EEPROM
(optional)
view from below
1
5
6
10
11
15
2 Data
3 No function
1
Adjustable sensor supply: Pin 12: 5 V ... 24 V
Pin 11: 0 V
