157Functions and outputs
HBMQuantumX
Analog output (1)
Nc
1 or 5
2 or 6
GND 1 or GND 3
3 or 7
4 or 8
GND 2 or GND 4
U1
Ground 1
1
2
3
4
5
6
7
8
Note (see also page
LEERER MERKER):
GND 1 : clamp 1 and 2
GND 2 : clamp 3 and 4
GND 3 : clamp 5 and 6
GND 4 : clamp 7 and 8
