3. Position the module vertically on the backplane and push it in carefully on the lower guide
rail back up to the stop.
Guide rails
Upper screwed clamping gland
a.f. 4.0
Lower screwed clamping gland
Fig. 4.20: Mounting the module
Fig. 4.21: Centering above the connection plug
