73Connection
HBMQuantumX
Connection to Port 3 − Port 4: 1 Hop
Connection to Port 1 and/or 2 − Port 4: 2 Hops
Port1
Phy 1
Phy 2
Port 1 Port 2 Port 3
Port 4
Port2 Port3
Port4
Fig.5.14: Connection situation at AVT 1394b hub
Note
Always connect the chain with the most modules to Port 3 or Port 4.
