5.2 Tool data
PITCH Thread pitch of the tool. Is used by Tapping cycles 206, 207 and
209 in order to monitor whether the pitch defined in the cycle
matches the pitch of the tool.
Input range in mm: -99999.99990 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
Thread pitch (only type TAP)?
AFC Control setting for the adaptive feed control AFC that you have
defined in the NAME column of the AFC.TAB table. Apply the
feedback-control strategy with the ASSIGN AFC CONTROL
SETTING soft key (3rd soft-key row)
Input range: 10 characters max.
Feedback-control strategy?
DR2TABLE 3D ToolComp: software option: Enter the name of the
compensation value table from which the TNC is to take the
angle-dependent delta radius values DR2 (see also "3-D tool radius
compensation depending on the tool’s contact angle (3D-
ToolComp software option)" on page 536)
Input range: Max. 16 characters without file extension
Compensation-value table?
LAST_USE Date and time that the tool was last inserted via TOOL CALL
Input range: Max. 16 characters, format specified internally: Date
= yyyy.mm.dd, time = hh.mm
Date/time of last tool call?
ACC Activate or deactivate active chatter control for the respective tool
(see also "Active Chatter Control (ACC—software option)" on page
451).
Input range: 0 (inactive) and 1 (active)
ACC status 1=active/0=inactive
CR Machine-dependent function: Transfer of a value to the PLC.
Refer to the machine manual.
Input range: -99999.9999 to +99999.9999
Value?
CL Machine-dependent function: Transfer of a value to the PLC.
Refer to the machine manual.
Input range: -99999.9999 to +99999.9999
Value?
Abbr. Inputs Dialog
