186 Programming: Tools
5.2 Tool data
Tool table: Tool data required for automatic tool measurement
For a description of the cycles for automatic tool
measurement, see the User's Manual for Cycle
Programming.
Abbr. Inputs Dialog
CUT Number of teeth (99 teeth maximum)
Input range: 0 to 99
Number of teeth?
LTOL Permissible deviation from tool length L for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L). Input
range: 0 to 0.9999 mm
Input range in mm: 0 to +0.9999
Input range in inches: 0 to +0.03936
Wear tolerance: length?
RTOL Permissible deviation from tool radius R for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L). Input
range: 0 to 0.9999 mm
Input range in mm: 0 to +0.9999
Input range in inches: 0 to +0.03936
Wear tolerance: radius?
R2TOL Permissible deviation from tool radius R2 for wear detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm: 0 to +0.9999
Input range in inches: 0 to +0.03936
Wear tolerance: Radius 2?
DIRECT. Cutting direction of the tool for measuring the tool during rotation Cutting direction (M3 = –)?
TT:R-OFFS Tool length measurement: Tool offset between stylus center and
tool center. Default setting: Tool radius R (NO ENT key enters R)
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
Tool offset: radius?
TT:L-OFFS Radius measurement: tool offset in addition to MP6530 between
upper surface of stylus and lower surface of tool. Default: 0
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
Tool offset: length?
