HEIDENHAIN iTNC 530 715
18.1 General user parameters
Configuring datum
table (To omit from the
table: enter 0); Column
number in the datum
table for
MP7268.0
Comment – DOC: 0 to 11
MP7268.1
Basic rotation – ROT: 0 to 11
MP7268.2
Datum in X axis – X: 0 to 11
MP7268.3
Datum in Y axis – Y: 0 to 11
MP7268.4
Datum in Z axis – Z: 0 to 11
MP7268.5
Datum in A axis – A: 0 to 11
MP7268.6
Datum in B axis – B: 0 to 11
MP7268.7
Datum in C axis – C: 0 to 11
MP7268.8
Datum in U axis – U: 0 to 11
MP7268.9
Datum in V axis – V: 0 to 11
MP7268.10
Datum in W axis – W: 0 to 11
Manual Operation
mode: Display of feed
rate
MP7270
Display feed rate F only if an axis direction button is pressed: 0
Display feed rate F even if no axis direction button is pressed (feed rate defined via soft key F or
feed rate of the “slowest” axis): 1
Set decimal places MP7280
The decimal character is a comma: 0
The decimal character is a point: 1
Select the
"Programming and
Editing" mode of
operation: Display of
multiline NC blocks
MP7281.0
Always show all NC blocks completely: 0
Only show current block completely: 1
Only show NC block completely when editing: 2
Select the "Program
Run" mode of
operation: Display of
multiline NC blocks
MP7281.1
Always show all NC blocks completely: 0
Only show current block completely: 1
Only show NC block completely when editing: 2
Position display in the
tool axis
MP7285
Display is referenced to the tool datum: 0
Display in the tool axis is referenced to the tool face: 1
Display step for the
spindle position
MP7289
0.1 °: 0
0.05 °: 1
0.01 °: 2
0.005 °: 3
0.001 °: 4
0.0005 °: 5
0.0001 °: 6
TNC displays, TNC editor
