716 Tables and Overviews
18.1 General user parameters
Display step MP7290.0 (X axis) to MP7290.13 (14th axis)
0.1 mm: 0
0.05 mm: 1
0.01 mm: 2
0.005 mm: 3
0.001 mm: 4
0.0005 mm: 5
0.0001 mm: 6
Disabling datum
setting in the preset
table
MP7294
Do not disable datum setting: %00000000000000
Disable datum setting in the X axis: Bit 0 = 1
Disable datum setting in the Y axis: Bit 1 = 1
Disable datum setting in the Z axis: Bit 2 = 1
Disable datum setting in the IVth axis: Bit 3 = 1
Disable datum setting in the Vth axis: Bit 4 = 1
Disable datum setting in the 6th axis: Bit 5 = 1
Disable datum setting in the 7th axis: Bit 6 = 1
Disable datum setting in the 8th axis: Bit 7 = 1
Disable datum setting in the 9th axis: Bit 8 = 1
Disable datum setting in the 10th axis: Bit 9 = 1
Disable datum setting in the 11th axis: Bit 10 = 1
Disable datum setting in the 12th axis: Bit 11 = 1
Disable datum setting in the 13th axis: Bit 12 = 1
Disable datum setting in the 14th axis: Bit 13 = 1
Disabling datum
setting
MP7295
Do not disable datum setting: %00000000000000
Disable datum setting in the X axis: Bit 0 = 1
Disable datum setting in the Y axis: Bit 1 = 1
Disable datum setting in the Z axis: Bit 2 = 1
Disable datum setting in the IVth axis: Bit 3 = 1
Disable datum setting in the Vth axis: Bit 4 = 1
Disable datum setting in the 6th axis: Bit 5 = 1
Disable datum setting in the 7th axis: Bit 6 = 1
Disable datum setting in the 8th axis: Bit 7 = 1
Disable datum setting in the 9th axis: Bit 8 = 1
Disable datum setting in the 10th axis: Bit 9 = 1
Disable datum setting in the 11th axis: Bit 10 = 1
Disable datum setting in the 12th axis: Bit 11 = 1
Disable datum setting in the 13th axis: Bit 12 = 1
Disable datum setting in the 14th axis: Bit 13 = 1
Disable datum setting
with the orange axis
keys
MP7296
Do not disable datum setting: %0
Disable datum setting with the orange axis keys: 1
TNC displays, TNC editor
