726 Tables and Overviews
18.3 Technical information
Teach-In Actual positions can be transferred directly into the NC program
Program verification graphics
Display modes
Graphic simulation before program run, even while another program is being run
Plan view / projection in 3 planes / 3-D view
Magnification of details
Programming graphics In the Programming and Editing mode, the contours of the NC blocks are drawn on
screen while they are being entered (2-D pencil-trace graphics), even while another
program is running
Program Run graphics
Display modes
Graphic simulation of real-time machining in plan view / projection in 3 planes / 3-D
view
Machining time Calculating the machining time in the Test Run mode of operation
Display of the current machining time in the Program Run modes
Contour, returning to Mid-program startup in any block in the program, returning the tool to the calculated
nominal position to continue machining
Program interruption, contour departure and return
Datum tables Multiple datum tables
Pallet tables Pallet tables (with as many entries as desired for the selection of pallets, NC programs
and datums) can be machined workpiece by workpiece or tool by tool
Touch probe cycles Calibrating the touch probe
Compensation of workpiece misalignment, manual or automatic
Datum setting, manual or automatic
Automatically measuring workpieces
Cycles for automatic tool measurement
Cycles for automatic kinematics measurement
Specifications
Components Main computer: MC 74xx or MC 75xx, MC 6441, MC 65xx or MC 66xx
Controller unit: CC 6106, 6108 or 6110
Remote keypad
15.1-inch or 19-inch TFT color flat-panel display with soft keys
IPC 6341 Industrial PC with Windows 7 (option)
Program memory At least 21 GB, depending on the main computer 130 GB
Input resolution and display
step
As fine as 0.1 µm for linear axes
As fine as 0.000 1° for rotary axes
Input range Maximum 99 999.999 mm (3.937 inches) or 99 999.999°
User functions
