HEIDENHAIN iTNC 530 727
18.3 Technical information
Interpolation Linear in 4 axes
Linear in 5 axes (subject to export permit) (software option 1)
Circular in 2 axes
Circular in 3 axes with tilted working plane (software option 1)
Helix:
Superimpositioning of circular and straight paths
Spline:
Execution of splines (3rd degree polynomials)
Block processing time
3-D straight line without radius
compensation
0.5 ms
Axis feedback control Position loop resolution: Signal period of the position encoder/1024
Cycle time of position controller: 1.8 ms
Speed controller cycle time: 600 µs
Cycle time of current controller: minimum 100 µs
Range of traverse Maximum 100 m (3937 inches)
Spindle speed Maximum 40 000 rpm (with 2 pole pairs)
Error compensation Linear and nonlinear axis error, backlash, reversal peaks during circular movements,
thermal expansion
Static friction
Data interfaces One each RS-232-C /V.24 and RS-422 / V.11 max. 115 kilobaud
Expanded interface with LSV-2 protocol for external operation of the TNC over the
interface with HEIDENHAIN software TNCremo
Ethernet interface 100BaseT
Approx. 2 to 5 megabaud (depending on file type and network load)
USB 2.0 interface
For pointing (mouse) devices and block devices (memory sticks, hard disks, CD-ROM
drives)
Ambient temperature Operation:0 °C to +45°C
Storage: -30°C to +70°C
