728 Tables and Overviews

18.3 Technical information

Accessories

Electronic handwheels  One HR 550 FS portable wireless handwheel with display or

 One HR 520 portable handwheel with display, or

 One HR 420 portable handwheel with display, or

 One HR 410 portable handwheel, or

 One HR 130 panel-mounted handwheel, or

 Up to three HR 150 panel-mounted handwheels via HRA 110 handwheel adapter

Touch probes  TS 220: Touch trigger probe with cable connection or

 TS 440: Touch trigger probe with infrared transmission

 TS 444: Battery-free touch trigger probe with infrared transmission

 TS 640: Touch trigger probe with infrared transmission

 TS 740: High-precision touch trigger probe with infrared transmission

 TT 140: Touch trigger probe for tool measurement
