HEIDENHAIN iTNC 530 93

2.4 Status displays

Global program settings 1 (GPS1 tab, software option)

Global program settings 2 (GPS2 tab, software option)

The TNC displays the tab only if the function is active on

your machine.

Soft key Meaning

No direct

selection possible

Swapped axes

Superimposed datum shift

Superimposed mirroring

The TNC displays the tab only if the function is active on

your machine.

Soft key Meaning

No direct selection

possible

Locked axes

Superimposed basic rotation

Superimposed rotation

Active feed rate factor
