5 June 2020 CasTemp Wireless including CasTemp Superheat Page 22
• The red LED next to the wireless symbol will be illuminated for 2 seconds.
• Next the battery LED will indicate the battery level at this moment. If the sensor is connected
to the QUBE CTW module, connection with the instrument can be initiated.
• The wireless LED will start flashing green after 4 seconds.
4.2.2.7 Set the CasTemp Wireless instrument in search mode
At start-up, the screen of Figure 19 is shown. No measurement is possible since the instrument is not
paired with a QUBE CTW module.
Figure 19: CTW start-up screen
Push the button on the front of the CasTemp wireless instrument for at least 1 second. A progress bar
will appear during the pushing.
Figure 20: CasTemp Wireless progress bar
