5 June 2020 CasTemp Wireless including CasTemp Superheat Page 5
9.7 Dual System Set up
CasTemp Superheat requires the use of a QUBE to take a measurement using a CasTip. Where two
CasTemp Wireless instruments are used on one casting machine, CasTemp Superheat software has
the ability to internally transfer messages between instruments which means there isn’t a requirement
to have two CasTip QUBEs thus reducing the complexity of the system. In order to use this feature
the following set up needs to be utilised:
• Connect the two instruments via TCP IP or ensure on the same network
• Set the IP address on the Master instrument
• Set the IP address on the slave instrument and tell this instrument to be a slave
Ready to cast telegram is very important in this mode as this is the instruction that tells the
instruments which one should display the measured liquidus. See the following example to see how
ready to casts tells the dual setup which instrument should display the liquidus.
Example One – CasTemp Wireless Master will display the Liquidus value
Example Two – CTW Slave will display the Liquidus value
