Heraeus Electro-Nite CasTemp Wireless - Hardware Requirements for CasTip Setup

5 June 2020 CasTemp Wireless including CasTemp Superheat Page 16
9.3 Hardware Requirements
CasTemp Superheat is based upon CasTemp Wireless so all the components required for the
standard CasTemp Wireless instrument set up are still required along with these additions:
Table of required equipment for CasTip set up:
Item
Component
UCS
SAP Description
Long Description
1
CasTip QUBE
Box
31010001
QUBE KIT CASTIP
includes x1 QUBE CASTIP,
X2 POWERPACK BATTERY
WIRELESS
And CHARGING STATION-
WIRELESS
2
CasTip QUBE
31090020
QUBE CASTIP
includes x1 POWERPACK
BATTERY WIRELESS
3
Battery
(Power Pack)
39970004
POWERPACK BATTERY
WIRELESS
4
Power Pack
Charger
39980258
CHARGING STATION-
WIRELESS
Includes 4 plugs
5
Lance / Pole
Handle
39800017
HANDLE W/CVR
W/CONN FEM 4P NON-
COMP
6
CasTip Probe /
Sensor Holder
20850960
CASTIP LANCE HOLDER
+ CTB + CABLE P1
(including 4m 2 core Cu-Cu
signal cable)
- NOTCHED
7
CasTip Sensor
-packed in box
of 12 pieces
10570661
CAST36000900 P360
UCS number is the complete
pallet of 30 boxes (360 pieces)
and smaller quantities.
A CasTip Lance will need to be prepared in order to take a CasTip measurement. A CasTip Lance
Assembly Guide Assembly Guide is shown in Appendix 7: QUBE CasTip Lance Build Guide and is
supplied with each CasTip Lance Holder.
9.3.1 CasTip QUBE
The CasTip QUBE connects to a manual dipping lance handle and transfers signal wirelessly to the
CTW instrument. This QUBE needs to be set to the location ID defined in the instrument.
• CasTip QUBE
• Battery Charger
• 2 x batteries
• User guide
9.3.2 Sensor / Probe Holder and Signal Cable (CASTIP LANCE HOLDER)
The probe holder comes ready made with a contact block and a 4m extension cable. This is non-
compensated cable as no part of the lance is expected to exceed 50°C. The 4m cable can be cut to
fix the length of the lance required. Please note 4m is the maximum standard length supplied.
