5 June 2020 CasTemp Wireless including CasTemp Superheat Page 13

8.4 CasTemp Wireless Instrument Specifications

CTW Instrument Power Specification

Voltage: 90-264VAC/ 47-63Hz Power: 34VA

CTW Instrument Temperature Specification

Max: 50°C Min: 0°C

CTW Instrument Humidity Specification

Max: 90% Min: 0%

QUBE CTW Module battery specification:

Voltage: 3.2v Amp Hour: 3Ah Watt Hour: 9.6Wh Chemistry: LiFePO4

8.5 QUBE CTW Module – repair

See Section 10.6 Appendix 6: QUBE CTW Module Repair Guide
