Highlight the required instrument and connect

The Remote client screen matches that of the instrument. This can be configured to show a large or a

small graph or the CasTemp Superheat application, if this is enabled.

10.4 Appendix 4: Profibus and Ethernet IP Module Installation and set up

Instrument will come with PCB pre-assembled ready for board installation but without the board

UCS number for options

UCS

CASTEMP WL PROFIBUS DP OPTON KIT

33201079

CASTEMP WL ETHERNET IP OPTON KIT

33201080
