6.3.1 Telegram Output
The following table shows the output of a telegram in the 4 possible conditons: paired; non-paired; loss of transmission or open cicuit.
Telegram Input
Paired
Not - Paired
Loss of Transmission
Open Circuit
Character
Length
Output
Value
Character
Length
Output Value
Character
Length
Output
Value
Character
Length
Output
Value
Instrument Name
16
CasTemp
Wireless
16
CasTemp Wireless
16
CasTemp
Wireless
16
CasTemp
Wireless
Module ID
4
A099
4
UUUU
4
LLLL
4
FFFF
Error State
4
0000
4
…@
4
0004
4
0004
Error Present
1
0
1
1
1
1
1
1
Battery Charge
4
100%
4
UUU%
4
LLL%
4
FFF%
System
TimeStamp
11
13:12:45 PM
11
02:57:44 AM
11
13:21:43 PM
11
04:02:35 AM
System
DateTimeStamp
19
13/02/2018
11:45:24
N/T
13/02/2018 11:45:24
N/T
13/02/2018
11:45:24
N/T
13/02/2018
11:45:24
Cold Junction
Temperature
5
022.4
5
UUU.U
5
LLL.L
5
FFF.F
Temperature
6
1500.1
6
UUUU.U
6
LLLL.L
6
FFFF.F
Battery Voltage
4
3323
4
UUUU
4
LLLL
4
FFFF
Signal Strength
3
081
3
UUU
3
LLL
3
FFF
