5 June 2020 CasTemp Wireless including CasTemp Superheat Page 25
4.2.2.10 QUBE CTW Module in Measurement Mode
The QUBE CTW module will blink as shown in Figure 26, at the interval set for transmission, see
Section 5.2.2 Configuring the CasTemp Wireless instrument parameters – sub section: Measuring
period of module.
Figure 26: QUBE CTW module after pairing
4.2.2.11 Pairing safety mechanism
To avoid that the CasTemp Wireless instrument is paired with the wrong QUBE CTW module a
number of safety procedures are implemented:
• Only 1 CasTemp Wireless instrument at a time can do a pairing procedure. If the system
detects that there is another instrument doing a pairing sequence in the same wireless range,
it will not continue in order to prevent from pairing with the wrong QUBE CTW module.
• The text of figure 27 is displayed.
Figure 27: Another pairing procedure is ongoing
