Heraeus Electro-Nite CasTemp Wireless - Configuring CasTemp Wireless Instrument Parameters; SH Prediction Parameters Configuration

5 June 2020 CasTemp Wireless including CasTemp Superheat Page 33
Setting
Default
Comment
Enable superheat
application
UNCHECKED
software will automatically check once license is loaded
– see superheat section 9.6
Enable master mode
UNCHECKED
only required to be checked when instrument is a master for dual
setup
– see superheat section 9.7
Enable slave mode
UNCHECKED
only required to be ticked when instrument is a slave for dual setup
– see superheat section 9.7.2
Enable QUBE
CasTip safety mode
CHECKED
Check this box to enable CasTip wireless safety mode.
– see superheat section 9.8.2
Enable QUBE
CasTip module lock
UNCHECKED
This box cannot be checked by the user – software will
automatically check this box when a module is locked to the
system. User can uncheck this box to allow new module to connect
to the system. Save settings for module lock do not take effect until
Settings menu is completely closed.
– see superheat section 9.8.2
Operator can unpair
CHECKED
Check if you want the operator to be able to unpair the instrument
through the instrument button.
Name of Instrument
CasTemp
Wireless
Optional
Master IP (Slave
mode)
GREYED OUT
only required in the dual setup when instrument is a slave
– see superheat section 9.7
Location ID
15
see table below for location ID advice
CTW pairing interval
30
This is the length of time once a module has been seen by the
instrument that the user has to pair that module.
CTW Searching
Interval
60
this is the length of time that the instrument will search for a module
once the pairing procedure is started
Measurement
Interval
15000
Measurement should be kept at 15000 unless required otherwise.
Contact local HEN rep for advice.
Open circuit interval
6000
This is the time between open circuit samples once the first open
sample is seen. This parameter is paired with the number of open
circuit samples to give a total open circuit unpairing timer.
No of open circuit
samples
10
This is the number of open circuit samples the instrument will allow
before module is unpaired.
No. of missed
transmissions
8
This is the number of consecutive signals the instrument will be
allowed to miss before it is unpaired. In this case it would be 8 x 15
seconds = 2 minute before unpairing
Suggested Location ID scheme: Example:
Caution:
Ensure each CasTemp Wireless instrument has a unique location ID. Two instruments
with the same Location ID, or the same Location ID on another member of the Qube
Wireless family may cause interference resulting in connection instability.
Plant Area
Location ID
Plant Area
1-15
Primary Steelmaking
30
Caster 1 Tundish Car 1
16-29
Secondary Steelmaking
31
Caster 1 Tundish Car 2
30-38
Continuous Casting
32
Caster 2 Tundish Car 3
39
Reserved: do not use
33
Caster 2 Tundish Car 4
41
Open Communication
