High End Systems MMS100 - Page 266

32769
0 degrees absolute
…
variable rotation angle
49151
720 degrees absolute
49152
rotation stop
49153
rotation cw slow
…
65535
rotation cw fast
96 + 97
89 + 90
X Scale Coarse
32768
0
max small 1:10
X Scale Fine
32786
1:1
65535
max large 10:1
98 + 99
91 + 92
Y Scale Coarse
32768
0
max small 1:10
Y Scale Fine
32786
1:1
65535
max large 10:1
100
+101
93 + 94
Z Scale Coarse
32768
0
max small 1:10
Z Scale Fine
32768
1:1
65535
max large 10:1
102 +
103
95 + 96
X Position
Coarse
32768
0
minimum left, -x axis
X Position Fine
32768
center
65535
maximum right, +x axis
104 +
105
97 + 98
Y Position
Coarse
32768
0
minimum down, -y axis
Y Position Fine
32768
center
65535
maximum up, +y axis
106 +
107
99 + 100
Z Position
Coarse
32768
0
minimum near, -z axis
Z Position Fine
32768
center
65535
maximum far, +z axis
108
101
(reserved)
0
0 thru 255
109
102
(reserved)
128
0 thru 255
Note 1 - Collage Type
Note 1
Collage Type
0
No collage selected.
1
Standard collage. Content will be sliced and diced by graphics engine.
2
Standard collage with 360 degree wrap
3
Multipane collage. Content will not be sliced and diced by graphics engine.
4
Multipane collage with 360 degree wrap
5 - 9
Reserved. Defaults to 0.
10
Standard collage plus blend right outside edge
11
Standard collage plus blend left outside edge
12
Standard collage plus blend bottom outside edge
13
Standard collage plus blend top outside edge
14
Standard collage plus blend right and bottom outside edges
15
Standard collage plus blend left and bottom outside edges
16
Standard collage plus blend right and top outside edges
17
Standard collage plus blend left and top outside edges
18
Standard collage plus blend left and right outside edges
19
Standard collage plus blend bottom and top outside edges
20
Standard collage plus blend right, left and bottom outside edges
21
Standard collage plus blend right, left and top outside edges
22
Standard collage plus blend right, bottom and top outside edges
23
Standard collage plus blend left, bottom and top outside edges
24
Standard collage plus blend right, left, bottom and top outside edges.
25 - 255
Reserved. Defaults to 0.
Note 2 - Collage Blending Adjustment
Note 2
Collage Blending Adjustment
0
Standard color blend curve.No adjustment.
1 - 63
Standard color blend curve.1 - 33, reduce intensity with 1 maximum reduction.
34, no intensity reduction or increase.Same as 0.
35 - 63, increase intensity with 63 maximum intensity increase.
64 - 127
Gray scale blend curve.64 - 95, reduce intensity with 64 maximum reduction.
96, no intensity reduction or increase.
