High End Systems MMS100 - Page 270

Horizontal Corner Opening
Towards
155
Geometry Correction -
Horizontal Corner Opening
Away
Correction
Horizontal Center
Vertical Center
156
Warp Map Output
Warp Number
Horizontal Scale
Vertical Scale
157
Optical Lens Aberration
Correction
Pincushion / Barrel
Correction
Pincushion / Barrel
Correction
(reserved)
158
Auto Z-rotation.
Rotation Mode
16bit rotation value
(first 8bit)
16bit rotation value
(second 8bit)
159
thru
254
(reserved)
(reserved)
(reserved)
(reserved)
255
Pan-and-Scan
Horizontal Position
Vertical Position
Zoom
Note 8 - Graphic Layer Effects Modes
Note 7
Global Effects
Modifier 1
Modifier 2
Modifier 3
0
Safe, No Effect Selected
(not used)
(not used)
(not used)
1
CMY
Cyan
Magenta
Yellow
2
CMY add to all pixels
Cyan
Magenta
Yellow
3
CMY add to non-black pixels
Cyan
Magenta
Yellow
4
RGB add to all pixels
Red
Green
Blue
5
RGB 2 add to all pixels
Red
Green
Blue
6
RGB add to non-black pixels
Red
Green
Blue
7
Swap color RGB to GBR
Red
Green
Blue
8
Swap color RGB to BRG
Red
Green
Blue
9
Solarize 1, if color value < dmx
value, invert color.
Red
Green
Blue
10
Solarize 2, if color value > dmx,
invert color.
Red
Green
Blue
11
Solarize 3, if color value < dmx, set
color to 0.
Red
Green
Blue
12
Solarize 4, if color value > dmx, set
color to 0.
Red
Green
Blue
13
dotP and resample.
Control Resample
Control Resample
Control Resample
14
Color Cycle,
Red
Green
Blue
15
All or Nothing.
Red
Green
Blue
16
Solid Color RGB
Red
Green
Blue
17
Invert RGB
Red to Inverted Red
Green to Inverted
Green
Blue to Inverted Blue
18
Invert & swap RGB to GBR.
Red to Inverted Green
Green to Inverted Blue
Blue to Inverted Red
19
Invert & swap RGB to BRG.
Red to Inverted Blue
Green to Inverted Red
Blue to Inverted
Green
20
Edge Detect Color.
Horz Search Size
Vert. Search Size
Comp. Threshold
21
Edge Detect BW.
Horz Search Size
Vert. Search Size
Comp. Threshold
22
Horizontal Texture Ripple.
Amplitude
Frequency
Phase
23
Vertical Texture Ripple.
Amplitude
Frequency
Phase Speed and
Direction
24
Circular Texture Ripple.
Amplitude
Frequency
Phase Speed and
Direction
25
Asymmetric Circular Texture
Ripple.
Amplitude
Frequency
Phase Speed and
Direction
26
Transparent Color, Fine
Red
Green
Blue
27
Transparent Color, Medium
Red
Green
Blue
28
Transparent Color, Coarse
Red
Green
Blue
29
Inverse Transparent Color, Fine
Red
Green
Blue
30
Inverse Transparent Color,
Medium
Red
Green
Blue
31
Inverse Transparent Color, Coarse
Red
Green
Blue
32
Scan Line
Line Select
Fade Amount
(not used)
33
Transparent Wipes
Width of Transparent
Area
Center of Transparent
Area
Transparency Mode
34
Pixel Twist
X-Twist Center
Y-Twist Center
Direction and Amount
35
Picture-in-Picture
X-Sub Picture Center
Y-Sub Picture Center
Sub Picture Size
36
Magnifying Lens
X-Lens Center
Y-Lens Center
Len Size
37
Magnifying Lens 2
X-Lens Center
Y-Lens Center
Len Size
