DS-76xx-I2/xP/4S NVR UM
101
Chapter 12 VCA Event Alarm
The device supports receiving VCA detections sent by connected IP cameras. Enable and configure VCA
detection on the IP camera settings interface.
VCA detections must be supported by the connected IP camera.
Refer to the User Manual of Network Camera for the detailed instructions for the VCA detection.
Human Body Detection
Human body detection is used to detect human bodies that appear in the monitoring scene, and
capture human body pictures.
This feature is available only when the connected camera supports human body detection.
1) Go to System > Event > Smart Event.
2) Click Human Body.
3) Select the camera to configure the human body detection.
4) Check Save VCA Picture to save the captured pictures of human body detection.
5) Check Target of Interest (Human Body) to discard non-human body pictures and videos which
are not triggered by human body detection.
6) Set detection area.
1) Select the detection area to configure from the Area drop-down list. Up to 8
detection areas are selectable.
2) Check the checkbox of Enable Area to enable the selected detection area.
3) Edit the area name in the Scene Name. The scene name can contain up to 32
characters.
Figure 12-1 Human Body Detection
