DS-76xx-I2/xP/4S NVR UM
68
Chapter 8 Disk Array
Purpose
Disk array is a data storage virtualization technology that combines multiple physical disk drive
components into a single logical unit. An array stores data over multiple HDDs to provide enough
redundancy so that data can be recovered if one disk fails. Data is distributed across the drives in one
of several ways called "RAID levels", depending on what level of redundancy and performance is
required.
Create Disk Array
Purpose
The device supports the disk array that is realized by software. You can enable the RAID function as
required. Two ways are available for creating array: one-touch configuration and manual configuration.
The following flow chart shows the process of creating array.
Enable RAID
Purpose
Perform the following steps to enable the disk array function.
1) Go to Storage > Advanced.
Figure 8-1 Advanced
2) Check Enable RAID.
3) Click Apply.
4) Reboot device to have settings take effect.
To Next Page
