DS-76xx-I2/xP/4S NVR UM
38
Chapter 4 Camera Settings
Configure OSD Settings
Purpose:
You can configure the OSD (On-screen Display) settings for the camera, including date/time, camera
name, etc.
1) Go to Camera > Display.
2) Select the camera from the drop-down list.
3) Edit the name in the Camera Name text field.
4) Check the checkbox of the Display Name, Display Date and Display Week if you want to show the
information on the image.
5) Set the date format, time format, and display mode.
Figure 4-1 OSD Configuration Interface
6) You can use the mouse to click and drag the text frame on the preview window to adjust the
OSD position.
7) Click the Apply button to apply the settings.
Configure Privacy Mask
Purpose:
The privacy mask can be used to protect personal privacy by concealing parts of the image from view
or recording with a masked area.
1) Go to Camera >Privacy Mask.
To Next Page
