DS-76xx-I2/xP/4S NVR UM
115
Figure 13-3 People Counting Interface
5) (Optional) Click Export to export the report in excel format.
Heat Map
Purpose:
Heat map is a graphical representation of data. The heat map function is usually used to analyze how
many people visited and stayed in a specified area.
The heat map function must be supported by the connected IP camera and the corresponding
configuration must be set.
1) Go to Smart Analysis > Heat Map.
2) Select a camera.
3) Select the report type as Daily Report, Weekly Report, Monthly Report, or Annual Report.
4) Set the Data to analyze.
Figure 13-4 Heat Map Interface
5) Click Counting. The results will ve displayed in graphics that are marked in different colors.
6) (Optional) Click Export to export the statistics report in excel format.
