DS-76xx-I2/xP/4S NVR UM
51
1) Click on the quick settings toolbar of the PTZ camera live view. The PTZ control panel
displays on the right of the interface.
2) Click Pattern to configure pattern.
Figure 6-12 Pattern Configuration
3) Select the pattern No. in the text field.
4) Set the pattern.
1) Click Record to start recording.
2) Click corresponding buttons on the control panel to move the PTZ camera.
3) Click Stop to stop recording.
The movement of the PTZ is recorded as the pattern.
5) Repeat steps 3 to 4 to set more patterns.
Call a Pattern
Purpose:
Follow the procedure to move the PTZ camera according to the predefined patterns.
1) Click on the quick settings toolbar of the PTZ camera live view. The PTZ control panel
displays on the right of the interface.
2) Click Pattern to configure pattern.
Figure 6-13 Pattern Configuration
3) Select a pattern in the text field.
4) Click Call to call it.
5) (Optional) Click Stop to stop calling it.
Set Linear Scan Limits
Before you start:
Please make sure the connected IP camera supports the PTZ function, and is properly connected.
