DS-76xx-I2/xP/4S NVR UM
95
Figure 11-6 Set Video Tampering Setting
3) Check Enable.
4) Set the video tampering area. Use the mouse to click and drag on the preview screen to draw
the customized video tampering area.
You can click Clear to clear the current area settings and draw again.
5) Set sensitivity level (0-2). 3 levels are available. The sensitivity allows you to calibrate how
readily movement triggers the alarm. The higher value results in the more readily to trigger the
video tampering detection.
6) Set the arming schedule. Refer to
Chapter 11.1 Configure Arming Schedule
.
7) Set the linkage actions. Refer to
Chapter 11.2 Configure Alarm Linkage Actions
.
Configure Sensor Alarms
Purpose:
Set the handling action of an external sensor alarm.
Configure Alarm Input
1) Go to System > Event > Normal Event > Alarm Input
2) Select an alarm input item from the list and click .
To Next Page
