DS-76xx-I2/xP/4S NVR UM
37
3) Click Add.
If the IP camera to add has not been actiavated, you can activate it from the IP camera list on the
camera management interface.
Configure the Customized Protocols
Purpose:
To connect network cameras that are not configured with the standard protocols, configure their
customized protocols. The system provides 16 customized protocols.
1) Click Protocol at the top taskbar to enter the protocol management interface.
Figure 3-4 Protocol Management
2) Select the transmission protocol type and choose the transfer protocols.
Type: the network camera adopting the custom protocol must support the getting of a
stream through standard RTSP
Path: contact the network camera manufacturer to obtain the URL (uniform resource
locator) for main stream and sub-streams
The URL format is: [Type]://[IP Address of the network camera]:[Port]/[Path]
Example
:
rtsp://192.168.1.55:554/ch1/main/av_stream
The protocol type and the transfer protocols must be supported by the connected IP camera.
Result:
3) After adding the customized protocols, you can see the protocol name is listed in the drop-
down list.
