DS-76xx-I2/xP/4S NVR UM
92
line crossing detection, intrusion detection, etc.)
2) Click the Trigger Alarm Output tab.
3) Select the alarm output(s) to trigger.
4) Go to System > Event > Normal Event > Alarm Output.
5) Select an alarm output item from the list.
Refer to
Chapter 11.6.3 Configure Alarm Output
for the alarm output settings.
Configure PTZ Linkage
The system can trigger the PTZ actions (e.g., call preset/patrol/pattern) when the alarm event, or VCA
detection events occur.
1) Go to the Linkage Action interface of the alarm input or VCA detection (e.g., line crossing
detection, intrusion detection, etc.)
2) Select the PTZ Linkage.
3) Select the camera to perform the PTZ actions.
4) Select the preset/patrol/pattern number to call when the alarm events occur. Only one PTZ type
can be set per linkage action at a time.
Figure 11-3 PTZ Linkage
Configure Motion Detection Alarm
The motion detection enables the device to detect the moving objects in the monitoring area and
trigger the alarm.
1) Go to System > Event > Normal Event > Motion Detection.
