DS-76xx-I2/xP/4S NVR UM
127
Figure 16-8 NTP Settings
2) Check Enable.
3) Configure NTP settings as needed.
Interval (min): Time interval between two time synchronization with NTP server.
NTP Server: IP address of the NTP server.
NTP Port: Port of the NTP server.
4) Click Apply.
Configure SNMP
Purpose
You can configure SNMP settings to get device status and parameter information.
Before You Start
Download the SNMP software to receive device information via SNMP port. By setting the trap address
and port, the device is allowed to send alarm event and exception message to the surveillance center.
1) Go to System > Network > Advanced > SNMP.
To Next Page
