DS-76xx-I2/xP/4S NVR UM
97
Figure 11-8 One-Key Alarm Disarming
6) Select the alarm linkage action(s) you want to disarm for local alarm input 1.
When the alarm input 1 (Local<-1) is enabled with one-key disarming, the other alarm input settings
are not configurable.
7) Click Apply to save the settings.
Configure Alarm Output
Trigger an alarm output when an alarm is triggered.
1) Go to System > Event > Normal Event > Alarm Output.
2) Select an alarm output item from the list and click .
3) Edit the alarm name.
4) Select the dwell time (the alarm duration) from 5s to 600s, or Manually Clear.
4) Manually Clear: you should manually clear the alarm when the alarm occurs. Refer to
Chapter 11.8
Trigger or Clear Alarm Output Manually
for detailed instructions.
5) Set the arming schedule. Refer to
Chapter 11.1 Configure Arming Schedule
.
To Next Page
