DS-76xx-I2/xP/4S NVR UM
93
Figure 11-4 Set Motion Detection
2) Select the camera to configure the motion detection.
3) Check Enable.
4) Set the motion detection area.
Full screen: click to set the full-screen motion detection for the image.
Customized area: use the mouse to click and drag on the preview screen to draw the
customized motion detection area(s).
You can click Clear to clear the current motion detection area settings and draw again.
5) Set sensitivity (0-100). The sensitivity allows you to calibrate how readily movement triggers
the alarm. The higher value results in the more readily to trigger the motion detection.
6) Set the arming schedule. Refer to
Chapter 11.1 Configure Arming Schedule
.
7) Set the linkage actions. Refer to
Chapter 11.2 Configure Alarm Linkage Actions
.
Configure Video Loss Alarm
Purpose
Video loss detection detects video loss on a channel and allows for appropriate alarm response
action(s) to be taken.
1) Go to System > Event > Normal Event > Video Loss
