DS-76xx-I2/xP/4S NVR UM
102
4) Click Draw Area to draw a quadrilateral in the preview window and then click Stop
Drawing.
You can click Clear to clear the existing virtual line and re-draw it.
7) Set the arming schedule. Refer to
Chapter 11.1 Configure Arming Schedule
.
8) Set the linkage actions. Refer to
Chapter 11.2 Configure Alarm Linkage Actions
.
9) Click Apply to activate the settings.
Vehicle Detection
Purpose
Vehicle Detection is available for road traffic monitoring. In Vehicle Detection, the passed vehicle can
be detected and the picture of its license plate can be captured. You can send alarm signal to notify
the surveillance center and upload the captured picture to a FTP server.
1) Go to System > Event > Smart Event.
2) Click Vehicle.
Figure 12-3 Vehicle Detection
3) Select a Camera to configure.
4) Check Enable Vehicle Detection.
5) Optionally, check Save VCA Picture to save the captured pictures of vehicle detection.
6) Set the arming schedule. Refer to
Chapter 11.1 Configure Arming Schedule
.
7) Set the linkage actions. Refer to
Chapter 11.2 Configure Alarm Linkage Actions
.
8) Configure rules, including Area Settings, Picture, Overlay Content, and Blacklist and Whitelist.
Area Settings: Up to 4 lanes are selectable.
