DS-76xx-I2/xP/4S NVR UM
83
Figure 10-8 Event Files
6) Click or to select the previous or next event.
Refer to
Chapter 11 Event and Alarm Settings
and
Chapter 12 VCA Event Alarm
for details for event and
alarm settings.
Refer to
Chapter 7.7 Configure Event Triggered Recording
for the event triggered recording/capture
settings.
Play by Sub-periods
Purpose:
The video files can be played in multiple sub-periods simultaneously on the screens.
1) Go to Playback.
2) Select Sub-periods from the drop-down list in the upper-left corner of the page to enter the
Sub-periods Playback interface.
3) Select a date and start playing the video file. Select the Split-screen Number from the dropdown
list. Up to 16 screens are configurable.
