DS-76xx-I2/xP/4S NVR UM
98
Figure 11-9 Alarm Output
6) (Optional) You can click Copy to copy the same settings to other alarm output (s).
Configure Exceptions Alarm
The exception events can be configured to take the event hint in the live view window, trigger alarm
output and linkage actions.
1) Go to System > Event > Normal Event > Exception.
2) (Optional) Enable the event hint if you want to display the event hint in the live view window.
1) Check the checkbox of Enable Event Hint.
2) Click to select the exception type(s) and take an event hint.
Figure 11-10 Event Hint Settings
