DS-76xx-I2/xP/4S NVR UM
89
Chapter 11 Event and Alarm Settings
Configure Arming Schedule
1) Select the Arming Schedule tab.
2) Choose one day of a week and set the time segment. Up to eight time periods can be set within
each day.
Time periods cannot be repeated or overlapped.
Figure 11-1 Set Arming Schedule
3) (Optional) If you want to copy the same arming schedule of the current day to the other day(s) of
the week or holiday, you can click the icon to copy arming schedule settings.
4) Click Apply to save the settings.
Configure Alarm Linkage Actions
Purpose:
Alarm linkage actions will be activated when an alarm or exception occurs, including Event Hint Display,
Full Screen Monitoring, Audible Warning (buzzer), Notify Surveillance Center, Trigger Alarm Output and
Send E-mail.
1) Click Linkage Action to set the alarm linkage actions.
