5.3 Performing Statistical Calculations on Measured Values
114
Statistical calculation results are displayed on the screen.
Additionally, results can be printed using an RS-232C printer. Once statistical calculation
results have been printed, the data can be automatically deleted.
Before printing, select the
[PRINT] interface setting.
See: "Printing (Using an RS-232C Printer)"(p.237)
The number of valid samples can be confirmed on the Calculation Results screen.
When the number of valid samples is zero, no calculation results are displayed.
When only one valid data sample exists, no standard deviation or process capability indi-
ces are displayed.
Confirming, Printing, and Erasing Calculation Results
1
Open the Calculation Results screen.
Displays the Calculation
Results screen (if statisti-
cal calculation is ON).
Switch the function menu
to P.1/3.
1
2
NUM Total data count
VAL Number of valid measured values
(error-free data)
AVG Mean
MAX Maximum
MIN Minimum
Sn Population standard deviation
Sn-1 Standard deviation of sample
Cp Process capability index (disper-
sion)
Cpk Process capability index (bias)
(When the comparator function is ON)
Hi Number of comparator Hi settings
IN
Number of comparator IN settings
Lo
Number of comparator Lo settings
(When the BIN function is ON)
BIN BIN setting range and IN judg-
ment count
Switching between statistical
results and BIN results
