Hioki RM3545 - Functions; Environment and Safety Specifications; Accessories

Chapter 13 Specifications
281
13
(1) Contact cycle count recording function
(2) Self-Test
(3) Relay hot switching prevention function
Functions
A contact cycle count of up to 999,999,999 can be recorded using control from the instrument with the
Z3003.
Each measurement pin’s round-trip wiring resistance value in the 2-terminal resistance measurement state
can be checked using control from the instrument with the Z3003.
The current flowing between the current generation terminals (SOURCE terminals) can be monitored using
control from the instrument with the Z3003.
Environment and Safety Specifications
Operating environment Indoors, Pollution degree 2, up to 2000 m (6562-ft.) ASL
Storage temperature
and humidity
-10°C to 50°C (14 to 122°F), 80%RH or less (non-condensating)
Operating temperature
and humidity
0°C to 40°C (32 to 104°F), 80%RH or less (non-condensating)
Applicable Standards
Safety
EMC
EN61010
EN61326 Class A
EN61000-3-2
EN61000-3-3
Effect of radiated radio-frequency electromagnetic field:
5%f.s. at 10V/m (added to the effect on the instrument with the Z3003)
Effect of conducted radio-frequency electromagnetic field:
5%f.s. at 3 V (added to the effect on the instrument with the Z3003)
Dimensions Approx. 92W × 24.5H × 182D mm (3.62"W × 0.96"H × 7.17"D)
(excluding protrusions)
Mass Approx. 180 g (6.3 oz.)
Accessories
Instruction Manual 1
D-SUB 50-pin connector 1 (pin header, solder cup)
