Chapter 13 Specifications
269
13
(1) Display
(2) Keys
Interface
LCD type Monochrome graphical LCD 240 × 110
Backlight White LED
Brightness adjustment range: 0 to 100% (5% increments), Default setting: 80%
When using EXT trigger source, brightness is automatically reduced when
keys are not used.
Brightness recovers upon front panel key operation.
Contrast Adjustment range: 0 to 100% (5% increments), Default setting: 50%
Measured value display
switching
In addition to normal measured values, the following are displayed:
No display/ temperature/ pre-calculation resistance value (TC, scaling, REF%,
T)
COMP, PANEL, , , , , MENU, F1, F2, F3, F4, ESC, ENTER, AUTO, , (RANGE),
(Standby), SPEED
Key-Lock Functions
Operation Disables operation of unneeded keys. Can also be canceled using a commu-
nication command.
Setting OFF/menu lock/all-key lock
Menu lock : Disables all keys other than direct keys (below) and the cancel
key.
COMP, PANEL, AUTO, , (RANGE), SPEED, 0ADJ, PRINT,
STAT, STOP
All-key lock: Disables all except the cancel key.
All front panel keys are disabled when the KEY_LOCK signal is
received.
Default setting OFF
Key-Press Beeper Setting
Setting ON/ OFF
Default setting ON
