Hioki RM3545 - Measurement

1.4 Screen Organization and Operation Overview
32
*1 RM3545-01 only
*2 RM3545-02 only
*3 When using the multiplexer, the selected channel number will be displayed next to “MEAS.”
Settings
screen
(SETTING)
System Setting
screen
(SYS)
TERMINAL
*2
Measurement terminal set-
tings
(p.148)
WIRE
*2
Multiplexer measurement
method
SCAN MODE
*2
Scan function
FAIL STOP
*2
Stop at FAIL during scan
SELF TEST
*2
Z3003 self-test (p.166)
STATISTICS Statistical calculations function (p.111)
TEMP INPUT
Temperature sensor settings (p.37) ANALOG SET1
ANALOG SET2
CALIBRATION Self-calibration (p.92)
KEY CLICK Set the operation sound (p.128)
COMP BEEP Hi
Set the judgment sound
(PASS/FAIL: RM3545-02
only)
(p.105)
IN
Lo
PASS
FAIL
PANEL LOAD 0ADJ Load zero-adjustment values (p.122)
CONTRAST Set the contrast (p.131)
BACK LIGHT Set the contrast brightness (p.132)
POWER FREQ Set the power frequency (p.129)
CLOCK Clock settings (p.133)
RESET Reset the instrument (p.134)
ADJUST Adjust the instrument (p.A43)
EXT I/O Setting
screen
(I/O)
TRIG SOURCE Set the trigger source (p.206)
TRIG EDGE Set the trigger signal logic (p.208)
TRIG/PRINT FILT Trigger/print filter function (p.210)
EOM MODE EOM signal setting (p.212)
JUDGE/BCD MODE EXT I/O output mode (p.214)
EXT I/O TEST EXT I/O test (p.215)
Communication
Interface
Setting screen
(IF)
INTERFACE Configure interface settings (p.221)
SPEED
Communications (p.219)
GP-IB
*1
DATA OUT
CMD MONITOR
PRINT INTRVL
Printing (p.237)PRINT COLUMN
STAT CLEAR
BIN Setting screen
(BIN)
BIN BIN measurement settings (p.108)
Screen Setting and key Overview See
