10.4 Ext
ernal I/O Sett
ings
210
The filter function, w
hich eliminates chatter, is useful when
connecting a foot switch or sim-
ilar device to
the TRIG/PRINT signal
.
Eliminatin
g TRIG/PRIN
T Signal Ch
atter (Fi
lter Function)
1
Open t
he Se
ttings
Screen.
2
Open t
he EX
T I/O
Setting
Scre
en.
3
Select the filter function.
The Settin
gs screen
appears.
Switch the function menu
to P.
2/3.
1
2
Move
the cur
sor to th
e [I/O]
tab with the left and right cur-
sor keys.
2
ON
OFF (defaul
t)
Selection
1
217
